Industrial Boiler, Engine & HVACR Analyser with KANE LINK
As KANE988 plus:
- Diagnose engine / exhaust / catalytic converter faults quickly
- Unique Non-Dispersive Infrared (NDIR) sensors designed to meet official test standards
- Identify fuel flow, misfire & EVAP problems
- Pre-compliance & roadside emissions tester - local laws may apply
- Measure Lambda & AFR to improve engine efficiency & fuel consumption
- Test engines under real world conditions
- Take analyser to vehicle, not vehicle to analyser
- Test vehicle A/C & refrigeration systems
Features
Sensor options - up to 4
- NO 0-5,000ppm
- NO2 0-1,000ppm*
- SO2 0-5,000ppm*
- H2S 0-200ppm
Probe & accessory options
- CHSLP5 1m high temperature PTFE lined smoke probe with removable shaft & 4m neoprene hose
- EP4 High temp stainless steel probe for motorcycle exhaust testing with 1.5m tubing & insertion depth of 230mm. Thermocouple to measure exhaust temp
- EP5 In cab heater probe with 4m neoprene tubing & insertion depth 350mm
- KMCE10 10m hose & thermocouple extension
- KANE-GCU* Gas conditioning unit
- KANE-IRP3 Printer
KANE LINK options
- KANE-WPCP2 Wireless LINK temp clamp probes - connect as a pair
- KANE-WPP2 Wireless LINK pass through pressure probes - connect as a pair
- KANE-DTHA2 Wireless LINK airflow, temp & RH
- KANE79 Wireless LINK CO monitor to 999ppm - connect up to 4
Applications
- Real time vehicle / engine testing in workshop & on road
- Instant engine, exhaust system & catalytic converter tests
- Vehicle smog checks, tune ups & diagnostics
- Check repair work with before & after test
- Maintain engines to manufacturer specification
- A/C & refrigeration performance & efficiency
Measures
- O2 0-21%
- CO 0-10,000ppm H2 compensated & 100,000ppm
- CO2 0-20%
- NO 0-5000ppm
- HC 0-5000ppm
- Option to measure 3 extra gases
- Differential temperature -20 to +135°C
- Differential pressure +/- 160mbar
Calculates
- CO/CO2 ratio
- Excess air
- Combustion efficiency
- NOx
- Lambda / AFR 0.8-1.2
- Superheat & Subcool
Fuel Types
- 12 standard fuels including:
- Natural Gas, LPG, Butane, Propane, Light Oil, Heavy Oil, plus 5 user fuels
- 40 refrigerants including:
- R22, R32, R134a, R290 & R410A
Box Contents
- Industrial Boiler, Engine & HVACR analyser supplied with pressure hose, SM50056 high capacity water trap & filter, CHSP5 & EP2 probe, CU12VDCA21 battery charger, MSC00117 protective pouch & 20106 backpack
Service Price
| YEAR 1 | YEAR 2 | YEAR 3 | YEAR 4 | YEAR 5 | UKAS Certification |
|---|---|---|---|---|---|
| £255 | £255 | £255 | £255 | £380 | £230 |
Calibration or Conformity Certificates included, as appropriate
All prices £ GBP, exclusive of VAT & subject to change.
All prices are in £ sterling and are exclusive of VAT.
